久保田零件查询M22502 STEP [AU] [NZ] HOOD/BONNETEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
480 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
K256155150
|
[1] |
STEP
|
17.6000(lbs); 8.000
|
| 020. |
0175450820
|
[2] |
BOLT FLANGE
|
0.0330(lbs); 0.015
|
| 030. |
K256155180
|
[2] |
TRIM FRAME
|
0.0154(lbs); 0.007
|
| 040. |
K256155310
|
[1] |
MAT STEP
|
2.3100(lbs); 1.050
|
| 050. |
K121184560
|
[11] |
PUSH RIVET
|
0.0044(lbs); 0.002
|
| 060. |
K256157310
|
[1] |
PLATE STEP
|
1.3200(lbs); 0.600
|
| 070. |
K256157320
|
[2] |
RIVET SCREW
|
0.0022(lbs); 0.001
|
| 080. |
0105350818
|
[2] |
BOLT
|
0.0242(lbs); 0.011
|
| 080. |
0175450820
|
[2] |
BOLT FLANGE
|
0.0330(lbs); 0.015
|
