约翰迪尔零件查询RE160299 - AXLE Axle Circulation Hoses and Axle CoolersEPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 290 次

Pos.	Part No	Qty	Parts name	Comments
1.	14M7296	[8]	Flange Nut	M10
2.	19M7786	[8]	Screw	M10 X 30
3.	19M7835	[4]	Screw	M10 X 35
4.	24M7296	[20]	Washer	10.500 X 30 X 2.500 MM
5.	38H1010	[4]	Elbow Fitting
6.	R26375	[6]	O-Ring
7.	T77613	[6]	O-Ring
8.	AT300845	[1]	Hydraulic Hose - Fabricate	11/16" X 4826 MM (190") X 11/16"
9.	AT300847	[1]	Hydraulic Hose - Fabricate	17.4752" X 3429 MM (135") X 17.4752"
10.	AT300848	[1]	Hydraulic Hose - Fabricate	17.4752" X 6731 MM (265") X 17.4752"
11.	AT300849	[1]	Hydraulic Hose - Fabricate	11/16" X 4572 MM (180") X 11/16"
12.	AT305165	[2]	Bracket
13.	AT307462	[1]	Bracket
14.	AT307463	[1]	Bracket
15.	AT307464	[1]	Heat Exchanger	(FRONT AXLE)
15.	AT307614	[1]	Oil Cooler	(FRONT AXLE) (HARSH ENVIRONMENT)
16.	H77698	[4]	Tie Band
17.	T162238	[18]	Grommet
18.	T201546	[12]	Grommet
19.	AT307465	[1]	Oil Cooler	(REAR AXLE)
19.	AT307615	[1]	Oil Cooler	(REAR AXLE) (HARSH ENVIRONMENT)
20.	38H1430	[1]	Elbow Fitting
21.	38H1005	[2]	Elbow Fitting
22.	T77857	[2]	O-Ring
23.	38H1170	[1]	Adapter Fitting
24.	R26286	[2]	O-Ring
25.	AT220734	[1]	Hydraulic Hose - Fabricate	13/16" X 735 MM (29") X 13/16"
26.	AT220735	[1]	Hydraulic Hose - Fabricate	13/16" X 3302 MM (130") X 13/16"
27.	AT220925	[2]	Oil Filter
28.	U12547	[2]	O-Ring
