| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 38H1030 | [1] | Tee Fitting | |
| 2. | T77613 | [6] | O-Ring | |
| 3. | 38H1067 | [2] | Adapter Fitting | |
| 4. | R26448 | [4] | O-Ring | |
| 5. | 24M7296 | [8] | Washer | 10.500 X 30 X 2.500 MM |
| 6. | AT116162 | [4] | Isolator | |
| 7. | T168393 | [4] | Clamp | |
| 8. | AT383857 | [2] | Accumulator Kit | |
| 9. | 19M7807 | [2] | Screw | M10 X 60 |
| 10. | AT225573 | [2] | Check Valve | |
| 11. | AT222414 | [2] | Hydraulic Hose - Fabricate | 17.4752" X 889 MM (35") X 17.4752" (INCLUDES T77613) |
| 12. | AT223768 | [1] | Hydraulic Hose - Fabricate | 17.4752" X 355 MM (14") X 17.4752" |
