久保田零件查询091200 CAMSHAFT KIT 1 [OPTION] ENGINEEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
151 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
1J02316930
|
[1] |
CAMSHAFT,KIT
|
4.3120(lbs); 1.960
|
| 020. |
1J02316010
|
[1] |
CAMSHAFT,ASSY
|
2.2110(lbs); 1.005
|
| 020. |
1A02316010
|
[1] |
CAMSHAFT,ASSY
|
2.3100(lbs); 1.050
|
| 030. |
0771500401
|
[1] |
BALL 1/4
|
0.0022(lbs); 0.001
|
| 040. |
1J09416510
|
[1] |
GEAR(CAM)
|
0.3740(lbs); 0.170
|
| 040. |
1G68716510
|
[1] |
GEAR(CAM)
|
0.5874(lbs); 0.267
|
| 050. |
0571200518
|
[1] |
FEATHER KEY
|
0.0066(lbs); 0.003
|
| 060. |
1584116270
|
[1] |
STOPPER(CAMSHAFT)
|
0.0594(lbs); 0.027
|
| 070. |
1G96204130
|
[1] |
GASKET,GEAR CASE
|
0.0616(lbs); 0.028
|
| 080. |
1J09404140
|
[1] |
SEAL,OIL
|
0.0286(lbs); 0.013
|
| 090. |
1584123250
|
[1] |
COLLAR,CRANKSHAFT
|
0.1100(lbs); 0.050
|
| 100. |
0481416220
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 110. |
1587524320
|
[1] |
RING,SNAP
|
0.0066(lbs); 0.003
|
