约翰迪尔零件查询9250 - BACKHOE VALVE MOUNTING BRACKET AND COVERS (JD350-B, JD450-B) [A14]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
393 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
14H812
|
[4] |
Nut
|
|
| 2. |
12H304
|
[4] |
Lock Washer
|
|
| 3. |
24H1305
|
[4] |
Washer
|
|
| 4. |
T40432
|
[1] |
Bracket
|
|
| 5. |
19H2472
|
[3] |
Cap Screw
|
|
| 6. |
12H301
|
[7] |
Lock Washer
|
|
| 7. |
19H2732
|
[4] |
Cap Screw
|
|
| 8. |
AT33311
|
[1] |
Box
|
|
| 9. |
19H2458
|
[2] |
Cap Screw
|
|
| 10. |
T34288
|
[1] |
Valve Cover
|
|
| 11. |
19H1227
|
[8] |
Cap Screw
|
|
| 12. |
12H302
|
[8] |
Lock Washer
|
|
| 13. |
24H1287
|
[8] |
Washer
|
|
| 14. |
T40351
|
[1] |
Valve Cover
|
|
| 15. |
14H1040
|
[4] |
Nut
|
|
| 16. |
19H2735
|
[4] |
Cap Screw
|
|
| 17. |
U41729
|
[1] |
Grommet
|
|
| 18. |
24H1625
|
[2] |
Washer
|
|
