约翰迪尔零件查询9250 - BACKHOE CONTROL LEVERS AND LINKAGE (JD350-B, JD450-B) [B03]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
466 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U43703
|
[4] |
Grip
|
|
| 2. |
U43214
|
[2] |
Lever
|
|
| 3. |
U14555
|
[2] |
Lock Nut
|
|
| 4. |
T34282
|
[2] |
Link
|
|
| 5. |
U11001
|
[2] |
Pin
|
|
| 6. |
34H330
|
[4] |
Spring Pin
|
|
| 7. |
U43216
|
[2] |
Lever
|
|
| 8. |
U10897
|
[2] |
Support
|
|
| 9. |
14H826
|
[2] |
Nut
|
|
| 10. |
T53976
|
[2] |
Support
|
|
| 11. |
11M7083
|
[2] |
Cotter Pin
|
|
| 12. |
H1609B
|
[4] |
Pin Fastener
|
|
| 13. |
11M7079
|
[4] |
Cotter Pin
|
|
| 14. |
T34284
|
[2] |
Link
|
|
| 15. |
34H339
|
[2] |
Spring Pin
|
|
| 16. |
U11003
|
[2] |
Pivot
|
|
| 17. |
11M7059
|
[2] |
Cotter Pin
|
|
