Pos.	Part No	Qty	Parts name	Comments
1.	U41161	[1]	Port Plate
2.	........	[14]	O-Ring	(B) 1/16" X 1-1/8" O.D. (SUB FOR U11326, THIS APPLICATION) ( T68666 NO LONGER AVAILABLE)
3.	........	[7]	O-Ring	(B) 1/16" X 1-3/4" O.D. (SUB FOR U15415, THIS APPLICATION) ( T68667 NO LONGER AVAILABLE)
4.	U41164	[2]	Orifice	.098"
5.	AU41882	[2]	Valve
6.	32240	[6]	O-Ring	(A) 3/32" X 1-1/16" O.D.
7.	U11427	[1]	Plug
8.	AU41885	[1]	Spool Valve
9.	AU40751	[2]	Pressure Relief Valve	17 238 KPA (173 BAR) (2500 PSI)
10.	AU41883	[1]	Spool Valve
11.	W11402	[1]	Orifice	.0785", (SUB FOR U41476)
12.	U41477	[1]	Orifice	.1130"
13.	AU40529	[1]	Pressure Relief Valve	16 376 KPA (164 BAR) (2375 PSI)
14.	AT34643	[1]	Spool Valve	(SUB FOR AU41886)
15.	U41166	[1]	Orifice	.1800", (USE WITH AU41884, BOOM VALVE)
15.	T36283	[1]	Orifice	.2340" (USE WITH AT35260, BOOM VALVE)
16.	AT35260	[1]	Spool Valve	(SUB FOR AU41884, THIS APPLICATION)
17.	AU40753	[1]	Relief Valve	12 928 KPA (129 BAR) (1875 PSI)
18.	AU40752	[1]	Pressure Relief Valve	18 961 KPA (190 BAR) (2750 PSI)
19.	U41160	[1]	End Plate
20.	12H303	[5]	Lock Washer	5/16"
21.	U41173	[5]	Cap Screw	5/16" X 12-3/4"
...	AT59144	[1]	Control Valve	REMANUFACTURED, (SUB FOR AU41880)
...	AU12404	[1]	Kit	(SUB FOR AU40973) REPAIR PLUG OR RELIEF VALVE
...	AU40972	[1]	O-Ring Kit	REPAIR SECTION ASSEMBLY
