约翰迪尔零件查询9250 - BACKHOE CROWD VALVE (JD300, JD400, JD401-A) [B09]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
857 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
P47908
|
[2] |
O-Ring
|
|
| 2. |
U40727
|
[2] |
Back-Up Ring
|
|
| 3. |
21H1206
|
[1] |
Screw
|
|
| 4. |
U42827
|
[1] |
Retainer
|
|
| 5. |
U42834
|
[1] |
Seal
|
|
| 6. |
U42835
|
[1] |
Washer
|
|
| 7. |
........
|
[1] |
Housing
|
|
| 8. |
B2762R
|
[1] |
O-Ring
|
|
| 9. |
U42833
|
[1] |
Clevis
|
|
| 10. |
P46051
|
[2] |
O-Ring
|
|
| 11. |
........
|
[1] |
Valve Spool
|
|
| 12. |
U41168
|
[1] |
Check Valve
|
|
| 13. |
U41170
|
[1] |
Spring
|
|
| 14. |
U41162
|
[1] |
Plug
|
|
| 15. |
T13119
|
[1] |
O-Ring
|
|
| 16. |
U41169
|
[1] |
Bushing
|
|
| 17. |
N31767
|
[2] |
Washer
|
|
| 18. |
U41167
|
[1] |
Bushing
|
|
| 19. |
U11336
|
[1] |
Spring
|
|
| 20. |
U11428
|
[1] |
Bolt
|
|
| 21. |
AU41892
|
[1] |
Cap
|
|
| ... |
AU41885
|
[1] |
Spool Valve
|
|
| ... |
AU12404
|
[1] |
Kit
|
|
| ... |
AU42191
|
[1] |
Kit
|
|
