约翰迪尔零件查询9250 - BACKHOE SWING VALVE (JD300, JD400, JD401-A) [B11]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 762 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU41892	[1]	Cap
2.	U11428	[1]	Bolt
3.	N31767	[2]	Washer
4.	U11336	[1]	Spring
5.	U41167	[1]	Bushing
6.	U41169	[1]	Bushing
7.	T13119	[1]	O-Ring	(C)
8.	U41162	[1]	Plug	3/32" X 3/4" O.D.
9.	P46051	[2]	O-Ring	(C) 3/32" X 7/16" O.D.
10.	U41170	[2]	Spring
11.	U41168	[2]	Check Valve
12.	........	[1]	Valve Spool	(SUB AT34643)
13.	U40727	[2]	Back-Up Ring	(A)
14.	P47908	[1]	O-Ring	(A) 3/32" X 15/16" O.D.
15.	........	[1]	Housing	SWING VALVE, (SUB AT34643)
16.	21H1206	[1]	Screw	1/4" X 5/16"
17.	U42827	[1]	Retainer
18.	U42834	[1]	Seal
19.	U42835	[1]	Washer
20.	U41172	[2]	Plunger
21.	N85304	[2]	Spring
22.	R394R	[2]	O-Ring	3/32" X 11/16"
23.	AN85149	[2]	Fitting	ASSEMBLY
24.	B2762R	[1]	O-Ring	(C) 9/64" X 1" O.D.
25.	U42833	[1]	Clevis
...	AT34643	[1]	Spool Valve	SWING, COMPLETE, (SUB FOR AU41886)
...	AU12404	[1]	Kit	(SUB FOR AU40973) REPAIR PLUG OR RELIEF VALVE
...	AU42191	[1]	Kit	REPAIR INDIVIDUAL VALVE
