约翰迪尔零件查询9250 - BACKHOE OIL LINES AND FITTINGS: MANIFOLD TO BOOM, CROWD, AND BUCKET CYLINDER [C08]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 607 次

Pos.	Part No	Qty	Parts name	Comments
1.	R26906	[5]	O-Ring
2.	R26375	[4]	O-Ring	(SUB FOR U10778)
3.	R26375	[2]	O-Ring
4.	AU42135	[2]	Hydraulic Hose - Fabricate	MANIFOLD TO BOOM CYLINDER, 1/2" X 56"
5.	TY3010	[1]	Hydraulic Hose	MANIFOLD TO L.H. CROWD TUBE, 1/2" X 45", (SUB FOR AU10860 AND AU13295)
6.	AU10861	[1]	Hydraulic Hose - Fabricate	MANIFOLD TO L.H. BUCKET TUBE, 1/2" X 3/4", (SUB FOR AU11506)
7.	AU10861	[1]	Hydraulic Hose - Fabricate	MANIFOLD TO R.H. BUCKET TUBE, 1/2" X 3/4", (SUB FOR AU42281 AND AU11506)
8.	AU10807	[1]	Hydraulic Hose - Fabricate	MANIFOLD TO R.H. CROWD TUBE, 1/2" X 42"
9.	AU11753	[3]	Union Fitting	UNION, STRAIGHT
10.	AU11752	[1]	Fitting	90°
11.	AU42218	[2]	Hydraulic Hose - Fabricate	1/2" X 28", (SUB AU11603 AND AU10810)
12.	U16163	[2]	Elbow Fitting	90°
13.	14H873	[2]	Nut	1-1/4"
14.	AU42283	[1]	Tube	L.H.
15.	AU42090	[2]	Oil Line
16.	AU42282	[1]	Tube	R.H.
17.	AU11603	[2]	Hydraulic Hose - Fabricate	1/2" X 28"
18.	U11273	[1]	Elbow Fitting	45°
19.	AU12217	[1]	Adapter	STRAIGHT
20.	U11009	[1]	Adapter	45°
21.	19H2633	[1]	Cap Screw	3/8" X 1-1/2"
22.	12H304	[3]	Lock Washer	3/8"
23.	U40447	[1]	Clamp
24.	U10516	[1]	Hose Clamp
25A.	U12288	[2]	Clamp
25B.	T38967	[2]	Clamp
26A.	........	[1]	Clamp	( U43468 USE IF AVAILABLE)
26B.	T38968	[2]	Strap
27.	19H2676	[2]	Cap Screw	3/8" X 1"
28.	AH16917	[2]	Adapter	STRAIGHT
29A.	14H873	[2]	Nut	1-1/4"
29B.	T11234	[2]	Lock Nut
30.	T11234	[1]	Lock Nut	3/8"
31.	U10516	[1]	Hose Clamp
32.	AU11849	[4]	Adapter	90°
33.	AU11603	[1]	Hydraulic Hose - Fabricate	711 MM (1/2" X 28") LONG, (SUB FOR AU42218, THIS APPLICATION)
34.	AU10810	[1]	Hydraulic Hose - Fabricate	(SUB FOR AU42218, THIS APPLICATION) 755 MM (1/2" X 30-1/2") LONG
