现代零件查询15LC/18LC/20LCA-7 LPG MIXER THROTTLE BODY ASSY(CERT)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
432 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
FT60M3113952003
|
[1] |
MIXER FT60 ASSY
|
|
| 2. |
F4-12
|
[2] |
FITTING-90
|
|
| 3. |
AF4-50430-001
|
[1] |
FITTING ASSY
|
|
| 4. |
G1-11
|
[1] |
GASKET-MIXER/ADAP
|
|
| 5. |
E1449100
|
[1] |
ADAPTOR
|
|
| 6. |
S3-50446-001
|
[1] |
SEAL
|
|
| 7. |
S3-50447-001
|
[2] |
SEAL
|
|
| 8. |
E1312100
|
[1] |
CONTROL-THROTTLE
|
|
| 9. |
32500782
|
[1] |
GASKET-AIR GOVERNOR
|
|
| 10. |
S1-69
|
[1] |
SCREW-MIXER
|
|
| 11. |
M0675
|
[4] |
BOLT
|
|
| 12. |
M0540
|
[4] |
BOLT
|
|
| 13. |
P1-30559
|
[1] |
PIN-RETAINER
|
|
