约翰迪尔零件查询9250A - BACKHOE SWING LINKAGE [A15]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 320 次

Pos.	Part No	Qty	Parts name	Comments
1.	A3581R	[1]	Spring Locking Pin	(SUB FOR 34H321)
2.	T68041	[1]	Pin	(SUB FOR U41722)
3.	JD7806	[2]	Lubrication Fitting	90°, 1/4"
4.	U43212	[2]	Bolt
5.	U43180	[4]	Spacer
6.	U43179	[4]	Tapered Sleeve
7.	T50103	[2]	Pin	TAPERED, SWING FRAME TO MAIN FRAME
8.	19H2717	[4]	Cap Screw	HS, SAE 8, 3/4" X 1-3/4"
9.	U40304	[1]	Bushing	UPPER SWING FRAME
10.	11M7030	[1]	Cotter Pin	5 X 40 MM
11.	U43218	[1]	Pin
12.	28316	[1]	Spring Locking Pin	(SUB FOR S2955DW, THIS APPLICATION)
13.	T33688	[4]	Bushing
14.	U40305	[1]	Bushing	LOWER, SWING FRAME
15.	AT46838	[1]	Frame	(INCLUDE U40304 AND U40305 BUSHINGS)
16.	19H2994	[2]	Cap Screw	HS, SAE 8, 5/8" X 1-1/2"
17.	U43183	[2]	Washer
18.	U43182	[2]	Tapered Sleeve	WEDGE
19.	U43219	[1]	Pin	TAPERED, BOOM CYLINDER TO SWING FRAME
20.	JD7797	[4]	Lubrication Fitting	STRAIGHT, 1/4"
21.	U11649	[4]	Washer
22A.	T37598	[2]	Pin	SWING CYLINDER ROD END
22B.	T59453	[2]	Groove Pin	SWING CYLINDER ROD END, (SUB T37598, (2) U11649 AND (2) 11H221, THIS APPLICATION)
22C.	T37598	[2]	Pin	SWING CYLINDER ROD END
23.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
24.	T59452	[4]	Snap Ring
25.	U11649	[4]	Washer
26.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
