现代零件查询15LC/18LC/20LCA-7 COLLANT HOSE & PIPEEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
230 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
25460-23C00
|
[1] |
PIPE ASSY-WATER INLET
|
|
| 2. |
25480-23C00
|
[1] |
HOSE ASSY-WATER INLET
|
|
| 3. |
25470-23C00
|
[1] |
PIPE ASSY-RADI
|
|
| 4. |
25471-23C00
|
[1] |
HOSE ASSY-RADI
|
|
| 5. |
25490-23C00
|
[1] |
PIPE ASSY-ENG TO RADI
|
|
| 5. |
25490-23C01
|
[1] |
Deleted...
|
|
| 6. |
11403-08146K
|
[4] |
BOLT-FLANGE
|
|
| 7. |
15717-17123
|
[5] |
PLUG-TAPER
|
|
| 8. |
11233-08223
|
[2] |
BOLT-WASHER ASSY
|
|
| 9. |
25631-23C00
|
[1] |
FITTING-WATER OUTLET
|
|
| 10. |
25633-23000
|
[1] |
GASKET-W/INLET FIT
|
|
| 11. |
25500-23001
|
[1] |
THERMOSTAT ASSY
|
|
| 12. |
11233-08557S
|
[1] |
BOLT-WASHER ASSY
|
|
| 13. |
13103-08007K
|
[1] |
NUT
|
|
| 14. |
13602-08006B
|
[1] |
WASHER-SPRING
|
|
| 15. |
39220-38020
|
[1] |
SENSOR & G/UNIT
|
|
| 16. |
25612-23C00
|
[1] |
HOUSING ASSY
|
|
| 17. |
25614-23000
|
[1] |
GASKET-THERMOSTAT
|
|
| 18. |
25462-23000
|
[2] |
O-RING,WATER PIPE
|
|
