| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | A3581R | [4] | Spring Locking Pin | |
| 2. | 08H4248 | [4] | Cap Screw | HEX., 5/8" X 8-1/2" (JD544) |
| 2. | 08H4260 | [4] | Cap Screw | HEX., 5/8" X 9" (JD644) |
| 3. | ........ | [2] | Pivot | (JD544) ( AT32300 USE IF AVAILABLE) |
| 3. | ........ | [2] | Pivot | (JD644) ( AT32512 USE IF AVAILABLE) |
| 4. | ........ | [2] | Stop | ( AT32299 USE IF AVAILABLE) |
| 5. | T22714 | [4] | Pin | |
| 6. | 12H294 | [4] | Lock Washer | 5/8" |
| 7. | 14H760 | [4] | Nut | 5/8" |
