| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | ........ | [1] | Bracket | ( BU10783 NO LONGER AVAILABLE) |
| 2. | 19H1734 | [2] | Cap Screw | HS, SAE 8, 5/8" X 2" |
| 2. | 12H294 | [2] | Lock Washer | 5/8" |
| 3. | 24H1448 | [2] | Washer | 1-1/32" X 1-1/2" X 0.120" |
| 4. | 08H4283 | [2] | Cap Screw | 1" X 12-1/2" |
| 4. | 12H234 | [2] | Lock Washer | 1" |
| 4. | 14H1048 | [2] | Nut | 1" |
| 5. | 19H2716 | [2] | Cap Screw | HS, SAE 8, 3/4" X 1-1/2" |
| 5. | 12H236 | [2] | Lock Washer | 3/4" |
| 6. | 8255CU | [5] | Weight |
