约翰迪尔零件查询93 - BACKHOE RESERVOIR, OIL FILTER, AND FENDER 610, 612, 616, 620, 622, AND 626 BULLDOZERS [D04]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 876 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H3239	[AR]	Cap Screw	HS, SAE 8, 3/8" X 1-1/4" (4 USED ON 1010)
1.	12H304	[AR]	Lock Washer	3/8", (4 USED ON 1010)
1.	14H812	[AR]	Nut	3/8", (4 USED ON 1010)
1.	19H2993	[AR]	Cap Screw	HS, SAE 8, 1/2" X 1-1/2" (4 USED ON 2010)
1.	12H301	[AR]	Lock Washer	1/2", (4 USED ON 2010)
1.	14H1040	[AR]	Nut	1/2", (SUB FOR 14H809) (4 USED ON 2010)
2.	........	[1]	Reservoir	( AU11761 NO LONGER AVAILABLE) WELDED, LESS OIL FILTER
3.	AP21910	[1]	Exhaust Cap	WITH DIP STICK
4.	U12603	[1]	Seal
5.	19H2676	[4]	Cap Screw	HS, SAE 8, 3/8" X 1"
5.	12H304	[4]	Lock Washer	3/8"
6.	........	[1]	Cap	( U12592 NO LONGER AVAILABLE)
7.	R460R	[1]	O-Ring	INLET TUBE
8.	U12605	[1]	Washer
9.	24H1227	[1]	Washer	17/32" X 13/16" X 0.060"
10.	U12595	[1]	Spring
11.	34H184	[1]	Spring Pin	1/8" X 1-1/8"
12.	........	[1]	Pin Fastener	(U12594 USE IF AVAILABLE)
13.	........	[1]	Bushing	( 28H2213 NO LONGER AVAILABLE) 3/8" X 6-1/2"
14.	U12610	[1]	Filter	ELEMENT, INLET
15.	U14868	[1]	Bowl
16.	R26375	[1]	O-Ring	(SUB FOR U10778)
17.	24H1379	[1]	Washer	11/16" X 1-3/4" X 0.036"
18.	U13965	[1]	Spring
19.	U12037	[1]	O-Ring	FILTER OUTLET
20.	AU11215	[1]	Oil Filter
21.	24M7296	[1]	Washer	10.500 X 30 X 2.500 MM
22.	19H3481	[1]	Cap Screw	HS, SAE 8, 3/8" X 7-1/2"
23.	15H690	[1]	Pipe Plug	CTSK, HD. 3/4"
24.	........	[1]	Support	( U13089 NO LONGER AVAILABLE) L.H. (FOR 1010)
25.	19H2676	[8]	Cap Screw	HS, SAE 8, 3/8" X 1"
25.	12H304	[8]	Lock Washer	3/8"
25.	14H812	[8]	Nut	3/8"
26.	........	[1]	Support	( U13192 NO LONGER AVAILABLE) L.H. (FOR 2010)
27.	15H592	[1]	Elbow Fitting	90°, 3/4"
28.	........	[1]	Elbow Fitting	90°, 1" ( 15H100 - NO LONGER AVAILABLE)
