约翰迪尔零件查询93 - BACKHOE CONTROL VALVE FOR CLOSED-CENTER HYDRAULIC SYSTEM 93 ( -005700) AND 95 ( -002450) 93 SERIESEPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
792 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U41161
|
[1] |
Port Plate
|
|
| 2. |
U11326
|
[14] |
O-Ring
|
|
| 3. |
U15415
|
[7] |
O-Ring
|
|
| 4. |
AU41882
|
[2] |
Valve
|
|
| 5. |
AU41885
|
[1] |
Spool Valve
|
|
| 6. |
AU41883
|
[1] |
Spool Valve
|
|
| 7. |
AT34643
|
[1] |
Spool Valve
|
|
| 8. |
AT35260
|
[1] |
Spool Valve
|
|
| 9. |
U41160
|
[1] |
Plate
|
|
| 10. |
12H303
|
[5] |
Lock Washer
|
|
| 11. |
U41173
|
[5] |
Cap Screw
|
|
| 12. |
T36283
|
[1] |
Orifice
|
|
| ... |
AU41881
|
[1] |
Valve
|
|
| ... |
AU41874
|
[1] |
Valve
|
|
| ... |
AU40972
|
[1] |
O-Ring Kit
|
|
