约翰迪尔零件查询93 - BACKHOE CROWD VALVE FOR AU40309, AU40310, AU41807 AND AU41809 CONTROL VALVES 93 ( -005700) AND 95 ( EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
448 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AU41892
|
[1] |
Cap
|
|
| 2. |
U11428
|
[1] |
Bolt
|
|
| 3. |
N31767
|
[1] |
Washer
|
|
| 4. |
U11336
|
[1] |
Spring
|
|
| 5. |
U11333
|
[1] |
Bushing
|
|
| 6. |
U11345
|
[1] |
Washer
|
|
| 7. |
U11427
|
[1] |
Plug
|
|
| 8. |
32240
|
[5] |
O-Ring
|
|
| 9. |
U40727
|
[2] |
Back-Up Ring
|
|
| 10. |
P47908
|
[2] |
O-Ring
|
|
| 11. |
........
|
[1] |
Spool
|
|
| 12. |
U40729
|
[1] |
Back-Up Ring
|
|
| 13. |
AU13748
|
[1] |
Check Valve
|
|
| 14. |
U16016
|
[1] |
Poppet
|
|
| 15. |
U16015
|
[1] |
Spring
|
|
| 16. |
U40728
|
[1] |
Back-Up Ring
|
|
| 17. |
R27928
|
[1] |
O-Ring
|
|
| 18. |
AU40529
|
[1] |
Pressure Relief Valve
|
|
| 19. |
........
|
[1] |
Housing
|
|
| 20. |
........
|
[1] |
|
|
| ... |
........
|
[1] |
Valve
|
|
| ... |
AU12404
|
[1] |
Kit
|
|
| ... |
AU13655
|
[1] |
Kit
|
|
