| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | JD179 | [2] | Union Fitting | 3/4" X 45° (95 ONLY) |
| 2. | AU11787 | [2] | Hydraulic Hose | 609 MM (3/4" X 24") |
| 3. | JD149 | [1] | Adapter | |
| 4. | JD182 | [1] | Hydraulic Hose | 914 MM (3/4" X 36") |
| 5. | 15H561 | [1] | Pipe Plug | RECESSED SOCKET HEAD, 1/2" |
| 6. | AU11654 | [1] | Fitting | STRAIGHT, 3/4" |
| 7. | AP23222 | [1] | Elbow Fitting | 3/4", 90° |
| 8. | 19H3065 | [3] | Cap Screw | 3/8" X 2" |
| 8. | 12H304 | [3] | Lock Washer | 3/8" |
| 8. | 14H812 | [3] | Nut | 3/8" |
| 9. | ........ | [6] | Clamp | (U13061 USE IF AVAILABLE) |
| 10. | AU10722 | [1] | Hydraulic Hose | 3 149.6 MM (3/4" X 124") |
