约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS FOR 1010 CRAWLER BULLDOZERS [G03]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 367 次

Pos.	Part No	Qty	Parts name	Comments
1.	AP23222	[2]	Elbow Fitting	3/4", 90° (93 ONLY)
2.	JD182	[1]	Hydraulic Hose	914.4 MM (3/4" X 36")
3.	JD149	[2]	Adapter	FEMALE, 3/4"
4.	AU11787	[3]	Hydraulic Hose	609.6 MM (3/4" X 24")
5.	15H599	[2]	Tee Fitting	3/4"
6.	29H638	[2]	Threaded Nipple	3/4" X 5-1/2"
7.	15H592	[3]	Elbow Fitting	3/4" X 90°
8.	29H710	[1]	Threaded Nipple	3/4" X 2-1/2"
9.	29H636	[1]	Threaded Nipple	3/4" X 4"
10.	........	[2]	Elbow Fitting	1", 90° ( 15H100 - NO LONGER AVAILABLE)
11.	........	[2]	Threaded Nipple	( U13084 NO LONGER AVAILABLE) 1" X 3"
12.	AR21840	[2]	Clamp	(SUB FOR R27542)
13.	........	[1]	Hydraulic Hose	( U13096 NO LONGER AVAILABLE) 2 679.7 MM (1-1/4" X 105-1/2")
14.	29H316	[1]	Threaded Nipple	1" X 3-1/2"
15.	U12547	[1]	O-Ring
16.	AU12366	[1]	Elbow Fitting	3/4" X 90°
17.	........	[1]	Hydraulic Hose	( JD183 NO LONGER AVAILABLE) 2 438 MM (3/4" X 96")
18.	AP23222	[1]	Elbow Fitting	3/4" X 90°
19.	L2296CU	[1]	Adapter	90°
20.	29H637	[1]	Threaded Nipple	3/4" X 10-1/2"
21.	U10275	[1]	Elbow Fitting	( AP23420 NO LONGER AVAILABLE) STREET 3/4", 90°
22.	29H729	[1]	Threaded Nipple	CLOSE, 3/4" X 1-1/2"
23.	15H621	[1]	Elbow Fitting	STREET, 3/4", 90°
24.	JD184	[1]	Elbow Fitting	1/2" X 45°
25.	TY3010	[1]	Hydraulic Hose	914.4 MM (1/2" X 36") (SUB FOR JD156)
26.	29H261	[1]	Threaded Nipple	3/4" X 3"
27.	........	[1]	Hydraulic Hose	( AP23420 NO LONGER AVAILABLE) 406. 4 MM (1/2" X 16")
28.	U10079	[1]	Elbow Fitting	3/4" X 1/2", 90° (FOR 610 AND 616 BULLDOZERS)
29.	U11273	[1]	Elbow Fitting	3/4" X 1/2", 45° (FOR 612 BULLDOZER)
30.	JD182	[1]	Hydraulic Hose	914.4 MM (3/4" X 36")
31.	U11277	[1]	Elbow Fitting	3/4", 90°
32.	U11273	[1]	Elbow Fitting	3/4" X 1/2", 45° (FOR 610 AND 616 BULLDOZERS)
32.	U10079	[1]	Elbow Fitting	3/4" X 1/2", 90° (FOR 612 BULLDOZER)
33.	U15939	[1]	Clamp
34.	19H2676	[1]	Cap Screw	HS, SAE 8, 3/8" X 1"
34.	12H304	[1]	Lock Washer	3/8"
34.	14H812	[1]	Nut	3/8"
