约翰迪尔零件查询93 - BACKHOE SNAP-TITE QUICK-DISCONNECT COUPLERS [G14]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
847 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
........
|
[1] |
Adapter
|
|
| 2. |
R31674
|
[2] |
O-Ring
|
|
| 3. |
........
|
[1] |
Valve
|
|
| 4. |
........
|
[1] |
Hyd. Quick-Connect Coupler
|
|
| 5. |
AT65849
|
[1] |
Threaded Nipple
|
|
| 6. |
U41352
|
[1] |
Back-Up Ring
|
|
| 7. |
R27149
|
[1] |
O-Ring
|
|
| 7. |
........
|
[1] |
O-Ring
|
|
| 8. |
........
|
[1] |
Housing
|
|
| 9. |
........
|
[1] |
Valve
|
|
| 10. |
AT65846
|
[1] |
HYDR.QUICK COUPLER SOCKET
|
|
| 11. |
R495R
|
[1] |
O-Ring
|
|
| 12. |
AU40877
|
[1] |
Plug
|
|
| 13. |
19H2676
|
[1] |
Cap Screw
|
|
| 13. |
12H304
|
[1] |
Lock Washer
|
|
| 13. |
14H812
|
[1] |
Nut
|
|
| 14. |
24M7296
|
[2] |
Washer
|
|
| 15. |
A4730R
|
[1] |
O-Ring
|
|
| 16. |
AU40876
|
[1] |
Cap
|
|
| ... |
AT36789
|
[1] |
Seal Kit
|
|
| ... |
AT65847
|
[1] |
Kit
|
|
