约翰迪尔零件查询9300 - BACKHOE MAIN FRAME [A12]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
1004 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H3520
|
[2] |
Cap Screw
|
|
| 2. |
T34559
|
[2] |
Pin
|
|
| 3. |
BP12214
|
[2] |
Lock Nut
|
|
| 4. |
14H794
|
[2] |
Nut
|
|
| 5. |
12H236
|
[2] |
Lock Washer
|
|
| 6. |
U16401
|
[2] |
Bushing
|
|
| 7. |
24H1236
|
[4] |
Washer
|
|
| 8. |
U16055
|
[2] |
Pin
|
|
| 9. |
11H277
|
[2] |
Cotter Pin
|
|
| 10. |
15H620
|
[1] |
Pipe Plug
|
|
| 11. |
19H3196
|
[2] |
Cap Screw
|
|
| 12. |
U41086
|
[2] |
Bushing
|
|
| 13. |
AT33299
|
[1] |
Main Frame
|
|
| 14. |
JD7759
|
[2] |
Lubrication Fitting
|
|
| 15. |
T34301
|
[4] |
Bushing
|
|
| 16. |
T67205
|
[2] |
Thrust Washer
|
|
| 17A. |
15H616
|
[1] |
Pipe Bushing
|
|
| 17B. |
15H589
|
[1] |
Pipe Bushing
|
|
| 18. |
AT36758
|
[1] |
Valve
|
|
| 18. |
AT72911
|
[1] |
Relief Valve
|
|
