约翰迪尔零件查询9300 - BACKHOE BACKHOE LEVER MOUNTING FRAME (SERIAL NO. 044298- ) [C10]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
417 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
14H785
|
[2] |
Nut
|
|
| 2. |
AT59836
|
[2] |
Link
|
|
| 3. |
T53972
|
[1] |
Pivot
|
|
| 4. |
19H2569
|
[2] |
Cap Screw
|
|
| 5. |
11M7079
|
[2] |
Cotter Pin
|
|
| 6. |
U11004
|
[2] |
Pin
|
|
| 7. |
19H2732
|
[4] |
Cap Screw
|
|
| 8. |
24H1305
|
[4] |
Washer
|
|
| 9. |
T53970
|
[1] |
Support
|
|
| 10. |
U16010
|
[2] |
Pin
|
|
| 11. |
21H304
|
[4] |
Lock Washer
|
|
| 12. |
14H812
|
[4] |
Nut
|
|
| 13. |
24H1274
|
[6] |
Washer
|
|
| 14. |
T53974
|
[2] |
Pin
|
|
| 15. |
T53977
|
[4] |
Snap Ring
|
|
| 16. |
T74317
|
[1] |
Lever
|
|
| 17. |
T34285
|
[2] |
Strap
|
|
