| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U42742 | [1] | Cutting Edge | SIDE, R.H., 1/2" X 3" X 31-3/4" (FOR 18", 24" AND 30" BUCKETS) (USE WITH BU40369, AT34975, AT34982, BU40370, AT34976, AT34984, BU40371, AT34977 AND AT34985) |
| 1. | T38857 | [1] | Cutting Edge | SIDE, R.H., 1/2" X 5" X 34-1/2" (FOR 18", 24" AND 30" BUCKETS) (USE WITH AT37722, AT37723 AND AT37724) |
| 1. | U42744 | [1] | Cutting Edge | SIDE, R.H., 1/2" X 4" X 27-1/2" (FOR 36" BUCKET) (USE WITH BU40372, AT34978 AND AT34986) |
| 1. | T38870 | [1] | Cutting Edge | SIDE, R.H., 1/2" X 5" X 30" (FOR 30" BUCKET) (USE WITH AT37725) |
| 2. | U42753 | [1] | Cutting Edge | FRONT, 5/8" X 6" X 16-3/4" (FOR 18" BUCKET) (USE WITH BU40369, AT34975 AND AT34982) |
| 2. | T38856 | [1] | Cutting Edge | FRONT, 7/8" X 6" X 16-3/4" (FOR 18" BUCKET) (USE WITH AT37722) |
| 2. | U42752 | [1] | Cutting Edge | FRONT, 5/8" X 6" X 22-3/4" (FOR 24" BUCKET) (USE WITH BU40370, AT34976 AND AT34984) |
| 2. | T38862 | [1] | Cutting Edge | FRONT, 7/8" X 6" X 22-3/4" (FOR 24" BUCKET) (USE WITH AT37723) |
| 2. | U42754 | [1] | Cutting Edge | FRONT, 7/8" X 6" X 28-3/4" (FOR 30" BUCKET) (USE WITH BU40371, AT34977 AND AT34985) |
| 2. | T38865 | [1] | Cutting Edge | (USE WITH AT37724) (FOR 30" BUCKET) |
| 2. | U42755 | [1] | Cutting Edge | FRONT, 5/8" X 6" X 34-3/4" (FOR 36" BUCKET) (USE WITH BU40372, AT34978 AND AT34986) |
| 2. | T38869 | [1] | Cutting Edge | FRONT, 7/8" X 6" X 34-3/4" (FOR 36" BUCKET) (USE WITH AT37725) |
| 3. | T36126 | [AR] | Shank | (SUB T417X230) TOOTH, 11/16" (4 USED WITH AT34975, AT34982, AT34976, AND AT34984, 5 USED WITH AT34977 AND AT34985, 6 USED WITH AT34978 AND AT34986) |
| 3. | U14436 | [AR] | Shank | (USE WITH BU40369, BU40370, BU40371 AND BU40372) TOOTH (4 USED WITH 18" AND 24" BUCKETS, 5 USED WITH 30" BUCKET, 6 USED WITH 36" BUCKET) |
| 3. | U43792 | [AR] | Bucket Tooth Adapter | (SUB FOR (AR) U42750) TOOTH, 15/16" (4 USED WITH AT37722 AND AT37723, 5 USED WITH AT37724, 6 USED WITH AT37725) |
| 3. | U43792 | [AR] | Bucket Tooth Adapter | (SUB FOR (AR) U42750) TOOTH, 15/16" (4 USED WITH AT37722 AND AT37723, 5 USED WITH AT37724, 6 USED WITH AT37725) |
| 4. | U42751 | [AR] | Point | TIP (4 USED WITH 18" AND 24" BUCKETS, 5 USED WITH 30" BUCKET, 6 USED WITH 36" BUCKET) (4 USED WITH AT34975, AT34982, AT34976, AND AT34984, 5 USED WITH AT34977 AND AT34985, 6 USED WITH AT34978 AND AT34986) |
| 4. | U14437 | [AR] | Point | (USE WITH BU40369, BU40370, BU40371 AND BU40372) TIP, (4 USED WITH 18" AND 24" BUCKETS, 5 USED WITH 30" BUCKET, 6 USED WITH 36" BUCKET) |
| 5. | U42743 | [1] | Cutting Edge | SIDE, L.H., 1/2" X 3" X 31-3/4" (FOR 18", 24" AND 30" BUCKETS) (USE WITH BU40369, AT34975, AT34982, BU40370, AT34976, AT34984, BU40371, AT34977 AND AT34985) |
| 5. | T38858 | [1] | Cutting Edge | SIDE, L.H., 1/2" X 5" X 34-1/2" (FOR 18", 24" AND 30" BUCKETS) (USE WITH AT37722, AT37723 AND AT37724) |
| 5. | U42745 | [1] | Cutting Edge | SIDE, L.H., 1/2" X 4" X 27-1/2" (FOR 36" BUCKET) (USE WITH BU40372, AT34978 AND AT34986) |
| 5. | T38871 | [1] | Cutting Edge | SIDE, L.H., 1/2" X 5" X 30" (FOR 36" BUCKET) (USE WITH AT37725) |
| 6. | ........ | [1] | Backhoe Bucket | (18") ( AT37722, USE IF AVAILABLE) (SUB AT114260) (SUB FOR BU40369, AT34975 AND AT34982) |
| 6. | ........ | [1] | Backhoe Bucket | (24") ( AT37723, USE IF AVAILABLE) (SUB AT114257) (SUB FOR BU40370, AT34976 AND AT34984) |
| 6. | ........ | [1] | Backhoe Bucket | (30") ( AT37724, USE IF AVAILABLE) (SUB AT114262) (SUB FOR BU40371, AT34977 AND AT34985) |
| 6. | ........ | [1] | Backhoe Bucket | (36") ( AT37725, USE IF AVAILABLE) (SUB AT114256) (SUB FOR BU40372, AT34978 AND AT34986) |
| 7. | AU41835 | [1] | Plate | L.H. (SUB AT36086) |
| 8. | T105987 | [2] | Bushing | (SUB FOR U42736) |
| 9. | T105988 | [4] | Bushing | (SUB FOR U42739) |
| 10. | 28H2240 | [1] | Bushing | 1-1/2" X 7" |
| 11. | U11650 | [2] | Washer | |
| 12. | 11H221 | [4] | Cotter Pin | 3/8" X 2-1/2" |
| 13A. | AU42333 | [1] | Pin Fastener | (SUB (2) U11650, (2) 11H221 AND T125926) BUCKET TO DIPPERSTICK |
| 13B. | T59450 | [1] | Pin Fastener | (SUB (2) U11650, (2) 11H221 AND T125926) BUCKET TO DIPPERCTICK |
| 13B. | T125926 | [1] | Pin Fastener | (DOES NOT INCLUDE WASHERS OR COTTER PINS) |
| 14. | AU41834 | [1] | Plate | R.H. (SUB AT36086) |
| 15. | U11649 | [2] | Washer | |
| 16A. | AU42334 | [1] | Pin Fastener | (SUB (2) U11649, (2) 11H221 AND T125931) COUPLER LINKS TO BUCKET |
| 16B. | T59451 | [1] | Pin Fastener | (SUB (2) U11649, (2) 11H221 AND T125931) COUPLER LINKS TO BUCKET |
| 16B. | T125931 | [1] | Pin Fastener | (DOES NOT INCLUDE WASHERS OR COTTER PINS) |
| 17. | T40910 | [AR] | Pin | FLEX (4 USED WITH 18" AND 24" BUCKETS, 5 USED WITH 30" BUCKET, 6 USED WITH 36" BUCKET) (SUB FOR U13927) |
| 18. | AT34983 | [AR] | Tooth | 11/16" (4 USED WITH AT34975, AT34976, AT34982 AND AT34984, 5 USED WITH AT34977 AND AT34985, 6 USED WITH AT34978 AND AT34986) (USE WITH 5/8" CUTTING EDGE) |
| 18. | ........ | [AR] | Tooth | 15/16" (4 USED WITH AT37722 AND AT37723, 5 USED WITH AT37724, 6 USED WITH AT37725) (USE WITH 7/8" CUTTING EDGE) ( AU41838 - NO LONGER AVAILABLE) (SUB T40910, U43792 AND U42751) |
| 19. | AT36086 | [1] | Plate | |
| 20. | T59445 | [2] | Snap Ring | |
| 21. | T59452 | [2] | Snap Ring |
