| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U42740 | [1] | Cutting Edge | SIDE, R.H., 5/8" X 4" X 27-1/2", (USE WITH BU40373, AT34979, AT34987, BU40374, AT34980, AT34988, BU40375, AT34981 AND AT34989) |
| 1. | T38875 | [1] | Cutting Edge | SIDE, R.H., 5/8" X 5" X 34-1/2", (USE WITH AT37726, AT37727, AT37728, AT76972, AT76971 AND AT76969) |
| 2. | U42753 | [1] | Cutting Edge | FRONT, 5/8" X 6" X 16-3/4" (FOR 18" BUCKET) (USE WITH BU40373, AT34979 AND AT34987) |
| 2. | T38856 | [1] | Cutting Edge | FRONT, 7/8" X 6" X 16-3/4" (FOR 18" BUCKET) (USE WITH AT37726 AND AT76972) |
| 2. | U42752 | [1] | Cutting Edge | FRONT, 5/8" X 6" X 22-3/4" (FOR 24" BUCKET) (USE WITH BU40374, AT34980 AND AT34988) |
| 2. | T38862 | [1] | Cutting Edge | FRONT, 7/8" X 6" X 22-3/4" (FOR 24" BUCKET) (USE WITH AT37727 AND AT76971) |
| 2. | U42754 | [1] | Cutting Edge | FRONT, 5/8" X 6" X 28-3/4" (FOR 30" BUCKET) (USE WITH BU40375, AT34981 AND AT34989) |
| 2. | T38865 | [1] | Cutting Edge | FRONT, 7/8" X 6" X 28-3/4" (FOR 30" BUCKET) (USE WITH AT37728 AND AT76969) |
| 3. | T40910 | [AR] | Pin | (A) (B) (C) FLEX, (SUB FOR U13927) |
| 4. | T36126 | [AR] | Shank | (A) (B) (C) (SUB T417X230) TOOTH, 11/16" |
| 4. | T417X230 | [AR] | Bucket Tooth Adapter | (A) (B) (C) |
| 4. | U43792 | [AR] | Bucket Tooth Adapter | (B) (C) (SUB FOR (AR) U42750) TOOTH, 15/16" |
| 5. | U42751 | [AR] | Point | (A) (B) (C) TIP |
| 6. | U42741 | [1] | Cutting Edge | SIDE, L.H., 5/8" X 4" X 27-1/2", (USE WITH BU40373, AT34979, AT34987, BU40374, AT34980, AT34988, BU40375, AT34981 AND AT34989) |
| 6. | T38876 | [1] | Cutting Edge | SIDE, L.H., 5/8" X 5" X 34-1/2", (USE WITH AT37726, AT37727, AT37728, AT76972, AT76971 AND AT76969) |
| 7. | AT37726 | [1] | Backhoe Bucket | 18", (SUB FOR BU40373, AT34979 AND AT34987) (SUB AT76972) |
| 7. | AT37727 | [1] | Backhoe Bucket | 24", (SUB FOR BU40374, AT34980 AND AT34988) (SUB AT76971) |
| 7. | AT37728 | [1] | Backhoe Bucket | 30", (SUB FOR BU40375, AT34981 AND AT34989) (SUB AT76969) |
| 8. | ........ | [1] | Plate | L.H., WITH BUSHINGS, (SUB AT36086) |
| 9. | T105987 | [2] | Bushing | (SUB FOR U42736) |
| 10. | T105988 | [4] | Bushing | (SUB FOR U42739) |
| 11. | 28H2240 | [1] | Bushing | 1-1/2" X 7" |
| 12. | U11649 | [2] | Washer | |
| 13. | 11H221 | [4] | Cotter Pin | 3/8" X 2-1/2" |
| 14A. | AU42334 | [1] | Pin Fastener | (SUB (2) U11649, (2) 11H221 AND T125931) COUPLER LINKS TO BUCKET |
| 14B. | T59451 | [1] | Pin Fastener | (SUB (2) U11649, (2) 11H221 AND T125931) COUPLER LINKS TO BUCKET |
| 14B. | T125931 | [1] | Pin Fastener | (DOES NOT INCLUDE WASHERS OR COTTER PINS) |
| 15. | ........ | [1] | Plate | (SUB AT36086) R.H. |
| 16. | U11650 | [2] | Washer | |
| 17A. | AU42333 | [1] | Pin Fastener | (SUB (2) U11650, (2) 11H221 AND T125926) BUCKET TO DIPPERSTICK |
| 17B. | T59450 | [1] | Pin Fastener | (SUB (2) U11650, (2) 11H221 AND T125926) BUCKET TO DIPPERSTICK |
| 17B. | T125926 | [1] | Pin Fastener | (DOES NOT INCLUDE WASHERS OR COTTER PINS) |
| 18. | AT34983 | [AR] | Tooth | 11/16" (3 USED WITH AT34979 AND AT34987, 4 USED WITH AT34980 AND AT34988, 5 USED WITH AT34981 AND AT34989) (USE WITH 5/8" CUTTING EDGE) |
| 18. | ........ | [AR] | Tooth | 15/16" (4 USED WITH BU40373, AT37726, BU40374 AND AT37727, 5 USED WITH BU40375 AND AT37728) (USE WITH 7/8" CUTTING EDGE) ( AU41838 - NO LONGER AVAILABLE) (SUB T40910, U43792 AND U42751) |
| 19. | AT36086 | [1] | Plate | |
| 20. | T59445 | [2] | Snap Ring | |
| 21. | T59452 | [2] | Snap Ring |
