约翰迪尔零件查询9500 - BACKHOE BOOM PIVOT [A17]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
182 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H3210
|
[4] |
Cap Screw
|
|
| 2. |
U14555
|
[3] |
Lock Nut
|
|
| 3. |
U41088
|
[2] |
Pin Fastener
|
|
| 4. |
19H3340
|
[2] |
Cap Screw
|
|
| 5. |
JD7797
|
[4] |
Lubrication Fitting
|
|
| 6. |
19H3544
|
[1] |
Cap Screw
|
|
| 7. |
U16051
|
[1] |
Pin
|
|
| 8. |
BP12214
|
[1] |
Lock Nut
|
|
| 9. |
U16070
|
[2] |
Bushing
|
|
| 10. |
19H3306
|
[2] |
Cap Screw
|
|
| 11. |
AU40588
|
[1] |
Frame
|
|
| 12. |
U10618
|
[2] |
Bushing
|
|
| 12. |
T126936
|
[2] |
Bushing
|
|
| 13. |
U41502
|
[2] |
Bushing
|
|
| 14. |
12H236
|
[4] |
Lock Washer
|
|
| 15. |
U41099
|
[1] |
Spacer
|
|
| 16. |
U40833
|
[2] |
Coupling
|
|
