现代零件查询15/18/20LC-7M FORKS & EXTENSION FORK(OPT)EPC Hyundai

广数供应链运营团队, 15 02月, 2025，浏览： 361 次

Pos.	Part No	Qty	Parts name	Comments
21.	64FP-12010G	[2]	FORK ASSY(750)	CHINA 1.5~1.8TON
21.	64FP-12020G	[2]	FORK ASSY(850)	CHINA 1.5~1.8TON
21.	64FP-12030G	[2]	FORK ASSY(900)	CHINA 1.5~1.8TON
21.	64FP-12040G	[2]	FORK ASSY(1050)	CHINA 1.5~1.8TON
21.	64FP-12050G	[2]	FORK ASSY(1200)	CHINA 1.5~1.8TON
21.	64FP-12060G	[2]	FORK ASSY(1350)	CHINA 1.5~1.8TON
21.	64FP-12070G	[2]	FORK ASSY(1500)	CHINA 1.5~1.8TON
21.	64FD-11010G	[2]	FORK ASSY(900)	CHINA 2.0TON
21.	64FD-11020G	[2]	FORK ASSY(950)	CHINA 2.0TON
21.	64FD-11030G	[2]	FORK ASSY(1000)	CHINA 2.0TON
21.	64FD-11040G	[2]	FORK ASSY(1050)	CHINA 2.0TON
21.	64FD-11050G	[2]	FORK ASSY(1150)	CHINA 2.0TON
21.	64FD-11060G	[2]	FORK ASSY(1200)	CHINA 2.0TON
21.	64FD-11070G	[2]	FORK ASSY(1350)	CHINA 2.0TON
21.	64FD-11080G	[2]	FORK ASSY(1500)	CHINA 2.0TON
21.	64FD-11090G	[2]	FORK ASSY(1600)	CHINA 2.0TON
21-1.	H200	[1]	PIN KIT
N21-11.	H501	[1]	KNOB
N21-12.	H502	[1]	SPRING PIN
N21-13.	H503	[1]	SPRING
N21-14.	H504	[1]	PIN
22.	69FJ-81010	[2]	EXT FORK ASSY(1300L)	1.5~1.8TON
22.	69FJ-81020	[2]	EXT FORK ASSY(1500L)	1.5~1.8TON
22.	69FJ-81030	[2]	EXT FORK ASSY(1700L)	1.5~1.8TON
22.	69FD-81010	[2]	EXT FORK ASSY(1300L)	2.0TON
22.	69FD-81020	[2]	EXT FORK ASSY(1500L)	2.0TON
22.	69FD-81030	[2]	EXT FORK ASSY(1700L)	2.0TON
22-1.	69FJ-81100	[1]	EXT FORK (1300L)	1.5~1.8TON
22-1.	69FJ-81200	[1]	EXT FORK (1500L)	1.5~1.8TON
22-1.	69FJ-81300	[1]	EXT FORK (1700L)	1.5~1.8TON
22-1.	69FD-81100	[1]	EXT FORK (1300L)	2.0TON
22-1.	69FD-81200	[1]	EXT FORK (1500L)	2.0TON
22-1.	69FD-81300	[1]	EXT FORK (1700L)	2.0TON
22-2.	69FJ-81500	[1]	LOCKING PIN
22-3.	S037-102026	[1]	BOLT-W/WASHER
