约翰迪尔零件查询9500 - BACKHOE SWING VALVE [B23]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 967 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU41892	[1]	Cap
2.	U11428	[1]	Bolt
3.	N31767	[2]	Washer
4.	U11336	[1]	Spring
5.	U41167	[1]	Bushing
6.	U41169	[1]	Bushing
7.	T13119	[1]	O-Ring	(A) (SUB FOR T57245)
8.	U41168	[2]	Check Valve
9.	........	[1]	Spool	(SUB AT34643)
10.	AU40815	[2]	Relief Valve	11 204 KPA (112 BAR) (1 625 PSI)
11.	32240	[2]	O-Ring	(B)
12.	U40727	[2]	Back-Up Ring	(B)
13.	P47908	[2]	O-Ring	(B)
14.	........	[1]	Housing	(SUB AT34643)
15.	21H1206	[2]	Screw	MACH., 1/4" X 5/16"
16.	U42827	[1]	Retainer
17.	U42834	[1]	Boot
18.	U42835	[1]	Washer
19.	U11326	[2]	O-Ring
20.	U15415	[1]	O-Ring
21.	U41172	[2]	Plunger	ANTI-CAVITATION
22.	R394R	[2]	O-Ring
23.	AN85149	[2]	Fitting
24.	N85304	[2]	Spring
25.	T57246	[1]	O-Ring	(A) (SUB FOR B2762R, THIS APPLICATION)
26.	U42833	[1]	Clevis
27.	P46051	[2]	O-Ring	(A)
28.	U41170	[2]	Spring
29.	U41162	[1]	Plug
30.	U11426	[2]	Orifice
31.	AT34643	[1]	Spool Valve
...	AU42191	[1]	Kit	REPAIR
...	AU12404	[1]	Kit	REPAIR RELIEF VALVE, (SUB FOR AU40973)
