约翰迪尔零件查询9500 - BACKHOE CROWD CYLINDER (SERIAL NO. -29445) [C02]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 575 次

Pos.	Part No	Qty	Parts name	Comments
1.	JD7788	[1]	Lubrication Fitting	45°, 1/4"
2.	U10745	[2]	Bushing
3.	AT32765	[1]	Hydraulic Cylinder Barrel	(SUB AT45783 AND AU10861)
4.	19H3239	[1]	Cap Screw	HS, SAE 8, 3/8" X 1-1/4"
4.	12H304	[1]	Lock Washer	3/8"
4.	24H1305	[1]	Washer	13/32" X 13/16" X 0.065"
5.	AT74728	[1]	Hydraulic Hose - Fabricate	(SUB FOR AT32769) (SUB FOR AW11542, THIS APPLICATION)
6.	AU11753	[1]	Union Fitting	STRAIGHT
7.	R26906	[1]	O-Ring	(A)
8.	22H842	[1]	Set Screw	1/4" X 5/16"
9.	L2235CU	[1]	Lock Nut
10.	U17337	[1]	Wear Ring	(A)
11.	U44578	[1]	Piston
12.	T37381	[1]	Packing	(A) (SUB FOR U12968, THIS APPLICATION) (SUB FOR R72830)
13.	R29463	[1]	O-Ring	(A)
14.	U44491	[1]	Piston Ring
15.	R76801	[1]	Packing	(A) (SUB FOR T35850)
16.	N10193	[1]	Snap Ring
17.	T33641	[1]	Piston
18.	L2301CU	[1]	O-Ring	(A)
19.	L2309CU	[1]	Back-Up Ring	(A)
20.	U41578	[1]	Wear Ring	(A) ROD GUIDE
21.	U43233	[1]	Tube	(SUB A5598R, R79122 AND R80937)
22.	L2029CU	[1]	Seal	(A)
23.	U11121	[2]	Bushing
24.	JD7759	[1]	Lubrication Fitting	STRAIGHT, 1/4"
25.	AT32767	[1]	Rod
...	AT32764	[1]	Cylinder	(SUB AT45782 AND AU10861)
...	AR105387	[1]	Hydraulic Cylinder Kit	(SUB FOR AT35938, AT36834, AT52710 AND AR96530)
