| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U11649 | [2] | Washer | |
| 1. | U11649 | [2] | Washer | |
| 2. | 11H221 | [4] | Cotter Pin | 3/8" X 2-1/2" |
| 2. | 11H221 | [4] | Cotter Pin | 3/8" X 2-1/2" |
| 3A. | AU42334 | [1] | Pin | BUCKET TO DIPPERSTICK |
| 3A. | AU42334 | [1] | Pin | BUCKET TO DIPPERSTICK |
| 3B. | T59451 | [1] | Pin | BUCKET TO DIPPERSTICK, (SUB AU42334) |
| 4. | U11651 | [2] | Washer | |
| 4. | U11651 | [2] | Washer | |
| 5A. | AU42426 | [1] | Pin | COUPLER LINKS TO BUCKET |
| 5A. | AU42426 | [1] | Pin | COUPLER LINKS TO BUCKET |
| 5B. | T59459 | [1] | Pin | COUPLER LINKS TO BUCKET, (SUB AU42426) |
| 6. | 28H2239 | [1] | Spacer | BUCKET LINKAGE, 1-1/4" X 7" |
| 7. | T59452 | [2] | Snap Ring | |
| 8. | T59447 | [2] | Snap Ring |
