Pos.	Part No	Qty	Parts name	Comments
1.	T34295	[1]	Port Plate	PORT, L.H.
2.	U11326	[14]	O-Ring
3.	U15415	[7]	O-Ring
4.	W22367	[7]	O-Ring
5.	AT64308	[3]	Valve	BUCKET AND STABILIZER, (SUB FOR AT33325)
6.	U44064	[2]	Orifice
7.	AT33326	[1]	Valve	CROWD
8.	P47889	[1]	O-Ring
9.	W23690	[1]	Back-Up Ring	(SUB FOR W19734)
10.	R459R	[1]	O-Ring
11.	AW15077	[1]	Plug
12.	AT39061	[2]	Relief Valve	17 238 KPA 172 BAR (2500 PSI)
13.	19H2472	[3]	Cap Screw	1/2" X 1", (VALVE-TO-VALVE BRACKET)
14.	12H301	[3]	Lock Washer	1/2", (VALVE-TO-VALVE BRACKET)
15.	AT33323	[1]	Relief Valve	16 376 KPA 164 BAR (2375 PSI)
16.	AT33328	[1]	Valve	SWING
17.	AT33327	[1]	Valve	BOOM
18.	T34298	[1]	Orifice	(5.56 MM)
19.	AT39062	[1]	Relief Valve	18 961 KPA (190 BAR)
20.	T34296	[1]	End Plate	END, R.H.
21.	12H304	[4]	Lock Washer	3/8"
22.	T34299	[4]	Cap Screw
...	........	[1]	Control Valve	(AT64309 NO LONGER AVAILABLE FURNISH COMPONENT PARTS) SIX SECTION, OPEN CENTER, COMPLETE, (SUB FOR AT46842)
