| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U12547 | [2] | O-Ring | |
| 2. | AU40260 | [1] | Adapter | STRIAGHT |
| 3. | U11461 | [1] | Elbow Fitting | 90° |
| 4. | AU11577 | [2] | Hydraulic Hose - Fabricate | 711 MM (3/8" X 28") |
| 5. | R26448 | [4] | O-Ring | |
| 6A. | AT46843 | [2] | Fitting | 90°, (SUB AT62866 AND (2) AU12083) |
| 6B. | AT62866 | [2] | Adapter | 90° |
| 7. | AU12083 | [2] | Hydraulic Hose - Fabricate | 610 MM (3/8" X 24") LONG, (SUB FOR AU11737 AND TY3000, THIS APPLICATION) |
| 8. | AT46832 | [2] | Union Fitting | 90° |
| 9. | AU42575 | [1] | Elbow Fitting | 90° |
