| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | LG691620 | [1] | Cotter Pin | |
| 2. | 11M7082 | [1] | Cotter Pin | 2.500 X 25 MM |
| 3. | 14H774 | [1] | Nut | 3/8" |
| 4. | 14M7272 | [4] | Nut | M6 |
| 5. | 19M7077 | [4] | Cap Screw | M6 X 20 |
| 6. | 24H1658 | [2] | Washer | 21/32" X 1" X 0.060" |
| 7. | AM1924T | [1] | Ball Joint | |
| 8. | AT194461 | [1] | Pedal | |
| 9. | AT195620 | [2] | Bearing With Housing | |
| 10. | T174528 | [1] | Pin Fastener | |
| 11. | T187279 | [1] | Stud | |
| 12. | T187280 | [1] | Rod | |
| 13. | T149199 | [1] | Label | (AUX HYD) |
| 14. | 24M7139 | [4] | Washer | 6.400 X 18 X 1.600 MM |
