约翰迪尔零件查询110 - BACKHOE, LOADER Bucket Cylinder (014000 - )EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
400 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
........
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 2. |
R26375
|
[2] |
O-Ring
|
|
| 3. |
38H1171
|
[2] |
Adapter Fitting
|
|
| 4. |
T77613
|
[2] |
O-Ring
|
|
| 5. |
AH172598
|
[1] |
Piston
|
|
| 6. |
H180241
|
[1] |
Bushing
|
|
| 7. |
AH175192
|
[1] |
Hydraulic Cylinder Rod
|
|
| 8. |
JD7798
|
[1] |
Lubrication Fitting
|
|
| 9. |
H219022
|
[1] |
Hydr. Cylinder Rod Guide
|
|
| 10. |
H170536
|
[1] |
Nut
|
|
| 11. |
H154514
|
[1] |
Seal
|
|
| 12. |
H155964
|
[1] |
O-Ring
|
|
| 13. |
R78393
|
[1] |
Back-Up Ring
|
|
| 14. |
H164204
|
[1] |
Snap Ring
|
|
| 15. |
H156058
|
[1] |
Wear Ring
|
|
| 16. |
H156586
|
[1] |
Seal
|
|
| 17. |
M44162
|
[1] |
O-Ring
|
|
| 18. |
H180248
|
[1] |
Snap Ring
|
|
| 19. |
AH224917
|
[2] |
Hydraulic Cylinder
|
|
| 20. |
H166438
|
[1] |
Back-Up Ring
|
|
| 21. |
R30200
|
[1] |
O-Ring
|
|
| 22. |
R88748
|
[1] |
Ring
|
|
| 23. |
R92208
|
[1] |
Packing
|
|
| 24. |
AH231936
|
[1] |
Hydraulic Cylinder Kit
|
|
