约翰迪尔零件查询210C - BACKHOE, LOADER Service Brake HydraulicsEPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 620 次

Pos.	Part No	Qty	Parts name	Comments
1.	T77814	[6]	O-Ring
2.	38H1166	[2]	Adapter Fitting
3.	R26287	[4]	O-Ring
4.	AT101003	[2]	Hydraulic Hose
5.	19M8183	[1]	Cap Screw	M10 X 90
6.	24M7040	[1]	Washer	11 X 20 X 2 MM
7.	AT101005	[1]	Oil Line
8.	AT101004	[1]	Oil Line
9.	38H1319	[2]	Elbow Fitting
10.	T14264	[2]	Clamp
11.	28H3377	[1]	Bushing	0.423" X 0.675" X 1-3/4"
12.	14M7296	[1]	Flange Nut	M10 ((2) USED ON 315CH)
13.	H77698	[1]	Tie Band
14.	AH89557	[2]	Clip
15.	19M7865	[2]	Screw	M8 X 16
16.	14M7273	[2]	Nut	M8
16.	14M7273	[1]	Nut	M8
16.	14M7273	[1]	Nut	M8
17.	28H2481	[1]	Spacer	0.423" X 0.675" X 1/2" (NOT REQUIRED ON 315CH)
18.	19M7932	[1]	Cap Screw	M8 X 16
18.	19M7932	[1]	Cap Screw	M8 X 16
19.	R27491	[1]	Clamp
19.	R27491	[1]	Clamp
20.	T128064	[1]	Bracket	(SUB FOR T122028)
21.	........	[1]	Oil Line	LEFT ( AT124959 NO LONGER AVAILABLE) (SUB AT172146)
22.	........	[1]	Oil Line	RIGHT ( AT124360 NO LONGER AVAILABLE) (SUB AT172145)
23.	AT124412	[2]	Hydraulic Hose - Fabricate
24.	24M7238	[1]	Washer	8.700 X 17 X 2 MM
25.	24H1314	[1]	Washer	13/32" X 1-3/4" X 7/64"
26.	AT172145	[1]	Kit	(SUB FOR AT124360)(RIGHT)
27.	AT172146	[1]	Kit	(SUB FOR AT124359)(LEFT)
