| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7847 | [4] | Screw | M16 X 180 |
| 1. | 19M7882 | [4] | Screw | M16 X 170 |
| 1. | 24M7241 | [4] | Washer | 17 X 34 X 4 MM (NOT ILLUSTRATED) |
| 2. | ........ | [1] | Counterweight | (SUB T106284 AND (4) 19M7960) T100901 NO LONGER AVAILABLE |
| 2. | ........ | [1] | Counterweight | ( T106284 NO LONGER AVAILABLE) (STANDARD EQUIPMENT FOR FACTORY INSTALLED EXTENDIBLE DIPPERSTICK) |
| 2. | ........ | [1] | Counterweight | (APPROXIMATE WEIGHT 415 LB.) (SUB T148381 T118899 USE IF AVAILABLE) |
| 2. | ........ | [1] | Counterweight | (APPROXIMATE WEIGHT 800 LB.) (SUB T150592 T125523 USE IF AVAILABLE) |
| 3. | ........ | [1] | Kit | ( AT86507 NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS) |
