| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T77832 | [4] | Self-Locking Screw | |
| 2. | AT101909 | [1] | Boot | |
| 3. | 28H1611 | [1] | Washer | 0.269" X 0.405" X 5/16" (USE WITH AT100589) |
| 4A. | AT135537 | [1] | Cover | (SUB FOR AT100589 AND AT114449, 28H1611) |
| 4B. | AT143468 | [1] | Cover | |
| 5. | 19M7932 | [4] | Cap Screw | M8 X 16 |
| 6. | 24H1822 | [4] | Washer | 11/32" X 7/8" X 1/16" (LOADER VALVE COVER TO FENDER CAPSCREWS) |
| 7. | H110232 | [4] | Washer | 10.310 X 22.600 X 1.500 MM (13/32" X 0.890" X 0.059") |
| 8. | AT143471 | [1] | Mounting Parts | |
| 9. | 24H1821 | [1] | Washer | 9/32" X 47/64" X 1/16" |
| 10. | T77835 | [1] | Self-Locking Screw | (SUB FOR T77834, THIS APPLICATION) |
