| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M8162 | [2] | Screw | M10 X 40 |
| 2. | AT101776 | [1] | Guard | |
| 3. | 14M7273 | [8] | Nut | M8 |
| 4. | 24H1822 | [11] | Washer | 11/32" X 7/8" X 1/16" |
| 5. | 19M7932 | [1] | Cap Screw | M8 X 16 |
| 6. | ........ | [1] | Cover | ( AT101767 NO LONGER AVAILABLE, ORDER FROM GANNON) |
| 7. | ........ | [1] | Bracket | ( AT101773 NO LONGER AVAILABLE, ORDER FROM GANNON) |
| 8. | 19M7288 | [1] | Cap Screw | M8 X 30 |
| 9. | 19M8008 | [3] | Cap Screw | M8 X 35 (SUB FOR 19M7298) |
| 10. | 24M7239 | [2] | Washer | 10.700 X 21 X 2.500 MM |
