| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T77613 | [3] | O-Ring | |
| 2. | 38H1172 | [2] | Adapter Fitting | |
| 3. | R26906 | [3] | O-Ring | |
| 4A. | AT100983 | [1] | Hydraulic Hose | 17.4752" X 1275 MM (50-1/4") X 17.4752" (SUB AT106692 AND 38H1004) |
| 4B. | AT106692 | [1] | Hydraulic Hose - Fabricate | 17.4752" X 1249 MM (49-1/4") X 17.4752" |
| 5. | AT135723 | [1] | Hydraulic Hose - Fabricate | 17.4752" X 1540 MM (60-3/4") X 17.4752" (SUB FOR AT100982 AND AT124201) |
| 6. | R26448 | [2] | O-Ring | |
| 7. | 38H1160 | [2] | Adapter Fitting | |
| 7. | 38H1160 | [1] | Adapter Fitting | |
| 8. | 38H1004 | [1] | Elbow Fitting | 90° |
