约翰迪尔零件查询210C - BACKHOE, LOADER HITCH LIFT CYLINDER (752372 - )EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
807 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R82552
|
[2] |
Bushing
|
|
| 2. |
R82557
|
[1] |
Wear Ring
|
|
| 3. |
RE21837
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 4. |
R81860
|
[1] |
Nut
|
|
| 5. |
R81774
|
[1] |
Scraper Ring
|
|
| 6. |
RE20342
|
[1] |
Seal
|
|
| 7. |
R82558
|
[1] |
Piston
|
|
| 8. |
R83469
|
[1] |
O-Ring
|
|
| 9. |
R81195
|
[1] |
Back-Up Ring
|
|
| 10. |
R81786
|
[1] |
Ring
|
|
| 11. |
RE21840
|
[1] |
Seal
|
|
| 12. |
R82556
|
[1] |
Seal
|
|
| 13. |
RE24533
|
[1] |
Seal
|
|
| 14. |
R82555
|
[1] |
Hydr. Cylinder Rod Guide
|
|
| 15. |
JD7781
|
[1] |
Lubrication Fitting
|
|
| 16. |
R81792
|
[1] |
Nut
|
|
| 17. |
RE21839
|
[1] |
Hydraulic Cylinder Rod
|
|
| 18. |
AH212089
|
[1] |
Hydraulic Cylinder Kit
|
|
| 19. |
RE21873
|
[1] |
Hydraulic Cylinder Kit
|
|
| 20. |
R91728
|
[AR] |
Back-Up Ring
|
|
| 21. |
........
|
[1] |
Hydraulic Cylinder
|
|
