Pos.	Part No	Qty	Parts name	Comments
1.	T20239	[1]	Gasket
2.	T20267	[1]	Cover
3.	T20268	[1]	Gasket
4.	T30897	[1]	Impeller	(SUB FOR T30897 OR R94419)
5.	T27261	[1]	Seal	(SUB AR101549)
6.	JD9257	[1]	Ball Bearing
7.	T19651	[1]	Hose Fitting
8.	T23631	[1]	Housing	GASOLINE, (SUB AT29618)
9.	R97758	[1]	V-Belt	(SUB FOR T20334)
10.	T23628	[1]	Pulley	(SUB FOR T30721) (ALSO ORDER (4) 19H3467)
11.	19H1912	[2]	Cap Screw	3/8" X 3-1/2"
12.	12H304	[4]	Lock Washer	3/8"
13.	14H812	[1]	Nut	3/8"
14.	19H3385	[1]	Cap Screw	1/2" X 1-1/8"
15.	19H1726	[1]	Cap Screw	3/8" X 2-1/4"
16.	R108404	[1]	Strap	ALTERNATOR ADJUSTING, (SUB FOR T20204 AND R107734)
17.	T25701	[1]	Stud
18.	AT34754	[1]	Fan
19.	24H1304	[1]	Washer	13/32" X 23/32" X 0.120"
20.	19H118	[4]	Cap Screw	5/16" X 1"
20.	19H2545	[2]	Cap Screw	3/8" X 1-3/8"
21.	19H3065	[2]	Cap Screw	3/8" X 2"
22.	15H584	[1]	Pipe Plug	1/2"
23.	AR41691	[1]	Seal Kit
24.	T30720	[1]	Hub	(SUB FOR R62371) (USE WITH T30721, NOT REQUIRED WITH T23628)
25.	AR101549	[1]	Seal Kit
26.	AT29618	[1]	Water Pump	GASOLINE, (MARKED T23631) (SUB FOR AT21205)
