约翰迪尔零件查询300B - BACKHOE, LOADER FUEL INJECTION SYSTEM (ENGINE SERIAL NO. 127776- ) (MANUFACTURED 1983 - ) [01D18]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
204 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
16H658
|
[1] |
Rivet
|
|
| 2. |
R51937
|
[6] |
Tube Nut
|
|
| 3. |
R51936
|
[6] |
Sealing Washer
|
|
| 4. |
R66090
|
[2] |
Tube
|
|
| 5. |
AR89839
|
[1] |
Fuel Line
|
|
| 6. |
T29969
|
[1] |
Clamp
|
|
| 7. |
19M7300
|
[2] |
Cap Screw
|
|
| 8. |
RE20901
|
[1] |
Clamp
|
|
| 9. |
RE20900
|
[1] |
Fuel Line
|
|
| 10. |
RE20899
|
[1] |
Fuel Line
|
|
| 11. |
RE19797
|
[1] |
Clamp
|
|
| 12. |
RE20898
|
[1] |
Fuel Line
|
|
| 13. |
R35352
|
[1] |
Fitting
|
|
| 14. |
14H785
|
[3] |
Nut
|
|
| 15. |
12H303
|
[3] |
Lock Washer
|
|
| 16. |
24H1243
|
[3] |
Washer
|
|
| 17. |
T23442
|
[3] |
Stud
|
|
| 18. |
R84663
|
[1] |
Gear
|
|
| 19. |
R48599
|
[1] |
Nut
|
|
| 20. |
R132874
|
[1] |
Washer
|
|
| 21. |
26H10
|
[1] |
Shaft Key
|
|
| 22. |
RE20896
|
[1] |
Fuel Injection Pump
|
|
