约翰迪尔零件查询300B - BACKHOE, LOADER TRANSMISSION PLUGS [01F11]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
512 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R27175
|
[1] |
Drain Plug
|
|
| 2. |
U12547
|
[1] |
O-Ring
|
|
| 3. |
T22853
|
[1] |
Sleeve
|
|
| 4. |
R31698
|
[1] |
Spring
|
|
| 5. |
R39294
|
[1] |
Pin Fastener
|
|
| 6. |
T24729
|
[2] |
Bushing
|
|
| 7. |
M1102T
|
[2] |
Plug
|
|
| 8. |
T20168
|
[3] |
Washer
|
|
| 9. |
19H2735
|
[3] |
Cap Screw
|
|
| 10. |
T17882
|
[1] |
Washer
|
|
| 11. |
R48685
|
[3] |
Dowel Pin
|
|
| 12. |
15H562
|
[1] |
Pipe Plug
|
|
| 13. |
19H2367
|
[1] |
Cap Screw
|
|
| 14. |
T22128
|
[1] |
Bushing
|
|
| 15. |
T26565
|
[2] |
Dowel Pin
|
|
| 16. |
34H247
|
[1] |
Spring Pin
|
|
| 17. |
AR26375
|
[1] |
Screen
|
|
| 18. |
A4808R
|
[1] |
Washer
|
|
| 19. |
R40147
|
[1] |
Fitting
|
|
| 20. |
34H246
|
[1] |
Spring Pin
|
|
