约翰迪尔零件查询300B - BACKHOE, LOADER DIFFERENTIAL DRIVE SHAFT [01F20]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 724 次

Pos.	Part No	Qty	Parts name	Comments
1.	16H1592	[8]	Rivet	7/16" X 1-3/4"
1.	T152922	[8]	Rivet	1/2" X 1 5/8"
2.	T31792	[AR]	Shim	0.05 MM (.002")
2.	T31793	[AR]	Shim	0.13 MM (.005")
2.	T31794	[AR]	Shim	0.25 MM (.010")
3.	JD8997	[1]	Bearing Cone
4.	JD8255	[1]	Bearing Cup
5.	T21975	[1]	Gear	FIRST AND FIFTH SPEED (40 TEETH)
6.	T21970	[2]	Shift Collar
7.	T21964	[2]	Sleeve
8.	T21976	[1]	Gear	SECOND AND SIXTH SPEED (36 TEETH)
9.	T21977	[1]	Gear	FOURTH AND EIGHT SPEED (27 TEETH)
10.	AT19966	[1]	Gear	(MARKED T21979) THIRD AND SEVENTH SPEED WITH BUSHING (31 TEETH)
11.	L32843	[1]	Nut	(SUB FOR T24917)
12.	T21965	[1]	Washer
13.	........	[AR]	Shim	(A) ( M2056T NO LONGER AVAILABLE) 0.05 MM (.002")
13.	........	[AR]	Shim	(A) ( M2057T NO LONGER AVAILABLE) 0.13 MM (.005")
13.	........	[AR]	Shim	(A) ( M2058T NO LONGER AVAILABLE) 0.25 MM (.010")
14.	JD8267	[1]	Bearing Cup
15.	JD8979	[1]	Bearing Cone
16.	R55721	[2]	Thrust Washer
17.	R56473	[1]	Thrust Washer
18.	R55722	[1]	Thrust Washer
19.	T24918	[1]	Washer
20.	T24382	[1]	Housing
20.	T30253	[1]	Housing	(ALSO ORDER (8) T30254)
20.	T149743	[1]	Housing	(ALSO ORDER (8) T152922)
21.	AT21620	[1]	Differential	R.H. (MARKED T24382) WITH RING GEAR (35 TEETH) (MARKED T21401 AND BEVEL PINION (8 TEETH) (MARKED T21402
21.	AT21622	[1]	Differential	R.H. (CONTAINS T30253 AND (8) T30254) (MARKED T30253) WITH GEAR, RING (MARKED T21401) (35 TEETH) AND PINION, BEVEL (MARKED T21402) (8 TEETH)
