约翰迪尔零件查询300B - BACKHOE, LOADER BRAKE VALVE OIL LINES [01J04]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
302 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R26287
|
[4] |
O-Ring
|
|
| 2. |
AT32335
|
[3] |
Elbow Fitting
|
|
| 3. |
AR65686
|
[1] |
Line
|
|
| 3. |
AR65687
|
[1] |
Line
|
|
| 4. |
24M7101
|
[1] |
Washer
|
|
| 5. |
R27528
|
[2] |
Clamp
|
|
| 6. |
12H304
|
[2] |
Lock Washer
|
|
| 7. |
19H1648
|
[2] |
Cap Screw
|
|
| 8. |
R27527
|
[1] |
Adapter Fitting
|
|
| 9. |
T21813
|
[2] |
Seat
|
|
| 10. |
U12547
|
[2] |
O-Ring
|
|
| 11. |
T21814
|
[2] |
Compression Spring
|
|
| 12. |
400R
|
[2] |
Ball
|
|
| 13. |
T21815
|
[2] |
Retainer
|
|
| 14. |
........
|
[2] |
Piston
|
|
| 15. |
T21817
|
[2] |
Spring
|
|
| 16. |
AR65688
|
[1] |
Line
|
|
| 16. |
AR65689
|
[1] |
Line
|
|
