约翰迪尔零件查询300B - BACKHOE, LOADER TELESCOPING DRAFT LINKS FOR CATEGORY I AND II HITCH [01J13]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
716 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
11M7030
|
[2] |
Cotter Pin
|
|
| 2. |
T22714
|
[2] |
Pin
|
|
| 3. |
AR68071
|
[1] |
Tie-Down Strap
|
|
| 4. |
AT30151
|
[1] |
Draft Link
|
|
| 4. |
AL26678
|
[1] |
Draft Link
|
|
| 5. |
AR28570
|
[2] |
Drawbar
|
|
| 6. |
F2208R
|
[2] |
Snap Ring
|
|
| 7. |
B2477R
|
[2] |
Spring Washer
|
|
| 8. |
T18716
|
[2] |
Washer
|
|
| 9. |
F2695R
|
[2] |
Extension Spring
|
|
| 10. |
D2865R
|
[2] |
Washer
|
|
| 11. |
F2693R
|
[2] |
Pin
|
|
| 12. |
AT30150
|
[1] |
Draft Link
|
|
| 12. |
AL26679
|
[1] |
Draft Link
|
|
| 13. |
T25767
|
[1] |
Bushing
|
|
| 14. |
AR62149
|
[1] |
Quick Lock Pin
|
|
