约翰迪尔零件查询300B - BACKHOE, LOADER SWINGING DRAWBAR [01J15]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 626 次

Pos.	Part No	Qty	Parts name	Comments
1.	T21677	[1]	Support	REAR
2.	T21913	[2]	Spacer	(USE WITH STRAIGHT DRAWBAR)
2.	L29023	[2]	Spacer	(USE WITH HEAVY-DUTY DRAWBAR)
3.	T21667	[1]	Drawbar	STRAIGHT, (SUB R61126 AND (2) L29023)
3.	R61126	[1]	Drawbar	HEAVY DUTY
4.	T21672	[1]	Support	FRONT, (SUB AR101210, THIS APPLICATION)
4.	AL27203	[1]	Support	FRONT
5.	12H301	[8]	Lock Washer	1/2"
6.	19H2898	[4]	Cap Screw	1/2" X 1-1/4"
7.	AT19850	[1]	Pin Fastener	(SUB AR101210, THIS APPLICATION)
8.	T22848	[1]	Spring Locking Pin
9.	19H1820	[4]	Cap Screw	1/2" X 3"
10.	T32016	[2]	Pin Fastener	(USE WITH STRAIGHT DRAWBAR)
11.	A3581R	[2]	Spring Locking Pin	(USE WITH STRAIGHT DRAWBAR)
12.	19H3550	[2]	Cap Screw	1/2" X 4", (USE WITH HEAVY-DUTY DRAWBAR)
13.	12H301	[2]	Lock Washer	1/2", (USE WITH HEAVY-DUTY DRAWBAR)
14.	14H1040	[2]	Nut	1/2", (USE WITH HEAVY-DUTY DRAWBAR)
15.	L32016	[1]	Pin Fastener	(USE WITH HEAVY-DUTY DRAWBAR)
16.	L31849	[1]	Adapter Fitting	(USE WITH HEAVY-DUTY DRAWBAR)
17.	AR101210	[1]	Kit
18.	19H2641	[1]	Cap Screw	5/8" X 3-1/4"
19.	18940	[1]	Clevis
20.	R1836R	[AR]	Washer
21.	M2023T	[1]	Lock Nut	(SUB FOR N101344)
