约翰迪尔零件查询300B - BACKHOE, LOADER REMOTE CYLINDER [01J19]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 833 次

Pos.	Part No	Qty	Parts name	Comments
1.	A4746R	[1]	Adapter Fitting	FEMALE
2.	A4745R	[3]	Packing	(B)
3.	A4747R	[1]	Washer	MALE
4.	A4748R	[1]	Spring Assembly
5.	R39006	[1]	Cylinder
6.	24H1301	[1]	Washer	13/32" X 9/16" X 0.065"
7.	A4737R	[1]	Spring
8.	A4738R	[1]	Washer
9.	A4736R	[1]	Rod
10.	A4739R	[2]	Ring
11.	A4741R	[1]	Spring
12.	A4742R	[1]	Ball
13.	A4740R	[1]	Valve
14.	AA5731R	[1]	Valve
15.	A4744R	[1]	Spring
16.	A4723R	[2]	Washer	(B)
17.	........	[1]	Washer	(B) ( R39029 USE IF AVAILABLE)
18.	R39013	[1]	Cover
19.	12H301	[4]	Lock Washer	1/2"
20.	19H2473	[4]	Cap Screw	HS, SAE 8, 1/2" X 1-3/4"
21.	R38508	[1]	Nut
22.	R39009	[2]	Back-Up Ring	(B)
23.	L2104N	[1]	O-Ring	(B)
24.	R39008	[1]	Piston
25.	A4733R	[1]	Washer	(B)
26.	A4732R	[1]	Guide
27.	25H760	[1]	Groove Pin	7/32" X 1-1/4"
28.	R27426	[1]	Arm
29.	A5302R	[1]	Yoke
30.	A147R	[1]	Washer
31.	A5301R	[1]	Stud
32.	R39064	[1]	Stop
33.	34H264	[1]	Spring Pin	5/32" X 7/8"
34.	AR38849	[1]	Rod
35.	AA5607R	[1]	Seal	(B)
36.	A4731R	[1]	Washer	(B)
37.	A4730R	[1]	O-Ring	(B)
38.	19H3483	[3]	Cap Screw	3/8" X 1-1/8"
39.	12H304	[3]	Lock Washer	3/8"
...	AR38713	[1]	Kit	CYLINDER OVERHAUL
...	15H561	[1]	Pipe Plug	1/2"
