约翰迪尔零件查询300B - BACKHOE, LOADER PROTECTIVE CANOPY [02A25]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 274 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT23477	[1]	Roof
2.	T25650	[2]	Isolator
3.	11M7059	[2]	Cotter Pin	3.200 X 20 MM L.H. (ALSO ORDER T36475 DECAL)
4.	24H1625	[2]	Washer	17/32" X 1" X 0.120" R.H.
5.	AT29422	[2]	Rod
6.	T26073	[2]	Handle
7.	T26072	[2]	Spring
8.	34H258	[2]	Spring Pin	5/32" X 1/2"
9.	T24818	[2]	Pin Fastener
10.	AT39014	[1]	Canopy	(HEAVY-DUTY LOADER)
11.	14H1039	[2]	Nut	5/8"
12.	12H294	[2]	Lock Washer	5/8"
13.	19H2599	[2]	Cap Screw	HS, SAE 8, 5/8" X 2-1/2"
14.	T25653	[2]	Pin Fastener	(USE WITH 24H1227) HEADED
14.	T46524	[2]	Pin Fastener	(USE WITH 24H1226)
15.	24H1227	[2]	Washer	17/32" X 13/16" X 0.060", (USE WITH T25653)
15.	24H1226	[AR]	Washer	1/2" X 1-1/4" X 0.083", (USE WITH T46524)
15.	24H1625	[2]	Washer	17/32" X 1" X 0.120", (USE WITH T46524)
16.	11H211	[2]	Cotter Pin	1/8" X 3/4"
17.	........	[1]	Isolator	(CUT TO LENGTH) (MAKE FROM AT186713)
18.	28H2499	[2]	Bushing	PIPE, 3/4" X 5/8", (SUB FOR T30622)
19.	14H1029	[2]	Wing Nut	1/2"
...	AT37159	[1]	Cab	(INCLUDES ALL PART NUMBERS LISTED ABOVE AND (2) T28451 FRONT MOUNTING SUPPORTS, SEAT BELT, AND AR38397 MUFFLER EXTENSION WITH CLAMP) (COMPLIES WITH CALIFORNIA SAFETY CODE)
