约翰迪尔零件查询300B - BACKHOE, LOADER LOADER BUCKET CYLINDER [02E12]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
685 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U10292
|
[2] |
Bushing
|
|
| 2. |
AU42144
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 3. |
R26375
|
[1] |
O-Ring
|
|
| 4. |
R39112
|
[1] |
Fitting
|
|
| 5. |
22H1077
|
[1] |
Set Screw
|
|
| 6. |
P45231
|
[1] |
Lock Nut
|
|
| 7. |
U17335
|
[1] |
Wear Ring
|
|
| 8. |
U17340
|
[1] |
Piston
|
|
| 9. |
T54815
|
[1] |
Packing
|
|
| 10. |
R495R
|
[1] |
O-Ring
|
|
| 11. |
U17339
|
[1] |
Piston
|
|
| 12. |
N51168
|
[1] |
Snap Ring
|
|
| 13. |
R76804
|
[1] |
Seal
|
|
| 14. |
U41825
|
[1] |
Wear Ring
|
|
| 15. |
R80909
|
[1] |
Hydr. Cylinder Rod Guide
|
|
| 16. |
F1870R
|
[1] |
O-Ring
|
|
| 17. |
R81194
|
[1] |
Back-Up Ring
|
|
| 18. |
U10296
|
[1] |
Seal
|
|
| 19. |
U13064
|
[2] |
Bushing
|
|
| 20. |
AU42146
|
[1] |
Hydraulic Cylinder Rod
|
|
| 21. |
JD7759
|
[1] |
Lubrication Fitting
|
|
| ... |
AU42141
|
[2] |
Hydraulic Cylinder
|
|
| ... |
RE19217
|
[1] |
Hydraulic Cylinder Kit
|
|
